■Outline

• Easy coupler-on installation to increase the boost pressure.
• Boost pressure increase data is preset to Power Editor.
• The reset connector is included. Connecting the connector can reset the data to its original after installing this product.
• Boost pressure increase data is preset to Power Editor.
  ※ Easy Writer is NOT included in the product. Download Easy Writer from HKS website.
  ※The provided USB connecting harness is required to connect with a PC.

■Main Functions

• Boost pressure increase for turbo vehicle：To increase the boost pressure of a stock vehicle.
• Status Confirmation LED：To check the unit status by LED.
• Edit the boost increase data: To edit the preset data to user's original data to increase the boost pressure.
  ※PC with Windows10, 8.1, 8, or 7 is required.

■Features

• Installing this Power Editor between the pressure sensor and pressure sensor harness can activate the boost increase function of this product.
• Easy Writer for Power Editor is available to edit the preset data.
  To edit by Easy Writer, connect Power Editor and PC using the provided USB harness.
• Replacing Power Editor with the provided reset connector can reset the data to the original and easily check the difference.
• Ideal for both MT & AT vehicle lightly tuned with aftermarket exhaust system, air cleaner, and/or catalyzer.

Easy Writer for Power Editor

■Preset Data

● HONDA CIVIC TypeR [FK8] (JDM)

■Performance

Type-R has the engine with originally overwhelming engine output. With Power Editor, the torque increases over the entire speed range, and driving becomes more powerful.

■Note

• This product is designed to be installed to a stock vehicle or vehicle that HKS products are installed.
• This product is to increase the boost pressure of the vehicle with stock turbine and not designed to use with the vehicle the upgraded turbo.
• This product is for a stock ECU data and not available to use with a customized data prepared by a ReFlash tool.

※Tuning ECU for MT model with "METAL CATALYZER" and/or "GT III-FX Turbine Kit" is under development. (Release will be 2019 Spring or later.)
